This PET preform injection machine is specially designed for the PET preform production industry. The PET preform adopts the optimized design of the professional PET screw group and the super large screw ratio of 25:1, which can effectively improve the defect rate in the preform production and improve the transparency of the product.
PET injection series is a new concept of PET preform injection molding machine, its design is based on more than 10 years of manufacturing experience and a good understanding of injection molding and PET preform technology, for beverage preforms, salad oil PET preforms, cosmetics / pharmaceutical preforms, our injection molding machine is more reliable and closer to market demand. Our injection molding machine is more compatible and suitable for various PET preform fields.
|
Model |
Clamping force |
Screw diameter |
Injection weight |
Motor power |
Heating power |
|
PET600/208S7 |
2080KN |
52mm |
611g |
23KW |
13.3KW |
|
PET800/208S7 |
2080KN |
60mm |
814g |
23KW |
16.5KW |
|
PET1200/208S7 |
2080KN |
67mm |
1209g |
27.8KW |
23.6KW |
|
PET1200/288S7 |
2880KN |
67mm |
1209g |
27.8KW |
23.6KW |
|
PET1500/288S7 |
2880KN |
75mm |
1515g |
36.5KW |
30.7KW |
|
PET1500/328S7 |
3280KN |
75mm |
1515g |
39.4KW |
30.7KW |
|
PET2300/328S7 |
3280KN |
83mm |
2369g |
39.4KW |
35.7KW |
|
PET3100/328S7 |
3280KN |
95mm |
3103g |
72KW |
45.3KW |
|
PET2300/388S7 |
3880KN |
83mm |
2369g |
39.4KW |
35.7KW |
|
PET3100/388S7 |
3880KN |
95mm |
3103g |
72KW |
45.3KW |
|
PET4500/388S7 |
3880KN |
100mm |
4521.6g |
36.5KWx2 |
55KW |
|
PET5000/388S7 |
3880KN |
105mm |
4984.8g |
36.5KWx2 |
61KW |
|
PET3100/458S7 |
4580KN |
95mm |
3103g |
72KW |
55KW |
|
PET4500/458S7 |
4580KN |
100mm |
4521.6g |
36.5KWx2 |
55KW |
|
PET5000/458S7 |
4580KN |
105mm |
4984.8g |
36.5KWx2 |
61KW |
|
PET6000/458S7 |
4580KN |
110mm |
5926.8g |
39KWx2 |
67KW |
|
PET7000/458S7 |
4580KN |
120mm |
7053.6g |
39KWx2 |
73KW |
|
PET8000/458S7 |
4580KN |
125mm |
8242.8g |
45KWx2 |
80KW |
